Ribbon Cable Connectors

1.ANTENK Insulation Displacement termination connectors are designed to quickly and effectively terminate Flat Cable in a wide variety of applications. The IDC termination style has migrated and been implemented into a wide range of connector styles because of its reliability and ease of use. Click on the appropriate sub section below depending on connector or application of choice.

   SPECIFICATION
Current Rating:                       1.0Amp
Insulation Resistance:            1000MΩ  min
Contact Resistance:               20mΩ  max
 Withstand Voltage:                500V AC/DC
Operating Temperature:  -40°C  to  +105°C
Contact Material:                    Phosphor Bronze
Contact Plating:                      Au  Over Ni
Insulator Material:              High Temperature plastic UL94V-0
